Outdoor lighting

Basic characteristics:

• many lights and push-buttons, usually in several places
• time-consuming adjustment of lighting to actual needs

• Scenes triggered by keys:
  • Smaller number of keys
  • Easier, faster adjustment of lighting to actual needs
  • Easy adaptation to lifestyle change
• Scenes can also be triggered automatically (schedule, at night)
• Lights can be included in other scenes (turn off everything when leaving home)

1. Configure inputs:
   1. Input 0 as low-light only time extend for Light 1
   2. Input 1 as low-light only time extend for Light 2
   3. Input 2 as low-light only time extend for Light 3
   4. Input 3 as toggle for Light 4
   5. Input 4 as toggle for Light 5
   6. Input 5 as toggle for Light 6
2. Configure timeouts:
   1. 30 s for Light 1
   2. 300 s for Light 2
3. Configure scenes:
   1. All off: scene 0 as all off
   2. Evening on: scene 1 as on for Lights 7, 8 and 9
   3. Evening off: scene 2 as off for Lights 7, 8 and 9
   4. Full: scene 3 as all on
4. Set schedules:
   1. Evening: set scene 1 at sunset scene 2 at midnight
