Intelligent Master Controller
Monitoring Control gateway with MODBUS/TCP IP & OPC
| Model number: | BM-C-A1 | |
|---|---|---|
| Description: | Battery Monitoring Master Controller | |
| Mounting: | DIN rail, 6M, 106mm | |
| Dimensions: | 106x108x58mm | |
Features
- Industrial grade reliability
- Update & upgrade from Cloud
- Alarms & log
- One controller per UPS
- Max. 4 battery strings with one controller
- 4 outputs for battery disconnection/alarm
- Unlimited number of controllers in network
- Optional: Connection of temperature sensors (directly)
- Optional: Connection of temperature/humidity sensors (on bus)
- Optional: Connection of RFID/Digital key reader for confirmation of physical check by staff
Safety standards
EN 61010-1, EN 61010-2-201, EN 61131-2
Technical specification
| Relay outputs: | 8A/250V |
| Communication: | Ethernet, 2x RS232, 1x RS485, IEX-2 bus |
| Nominal power rating: | 230 VAC |
| Power consumption: | typ. 1W (no load), 10W max |
| Power output: | 24V 200mA (IEX-2 + terminals) |
| Ingress protection: | IP20 |
| Operating temperature: | 0..45°C |
| Storage temperature: | -20..75°C |
| Relative humidity: | 0..95% n/c |
